Back View Camera(ICA-2419N/P)

Model Number

ICA-2419N/P

ITEM	DESCRIPTION
	1CA-2419N NTSC 270K PIXEL	ICA-2419P PAL 320K PIXEL
1. Image device	Interline Transfer CCD
2. Total Pixels	NTSC : 542(H) X 492(V)	PAL : 542(H) X 582(V)
3. Scanning system	2:1 interlace
4. Synchronization System	Internal
5. Horizontal Resolution	420 TV Lines
6. Sensitivity	0.5 Lux
7. Electronic Iris	Auto 1/60 ~ 1/100,000	1/50 ~ 1/100,000
8. Signal Processing	DSP
9. Video Output	1.0 Vp-p(-10% ~ +10%), 75ohm
10. S/N Ratio	More than 46dB
11. Power Supply	12V DC(9V ~ 14V)
12. Power Consumption	Max 110mA (w/IR LED)
13.Operating Temperature	- 10 ~ + 50
14.Operating Humidity	Max RH 95%
15. Dimension	410(L) X 370(H) X 420(D)mm
16. Aplied Lens	DIA150
17. Weight	1300g

<DIMENSION>
